Low emittance 2GeV 6 1.9T wigglers in L0, mirror in l3

December 6, 2007

/nfs/cesr/user/dlr/lat/des/CesrTF/rfa/l3

• Wall: 4.45cm from mbeam line and tangent to flm window and mirror in l3.




• l3 wall: outside wall and table

  &synrad_params
  	sr_param%lat_file = "hep_pretz.bmad"
          beam_direction = -1
  	sr_param%i_beam = 0.1          ! Beam current.
  	sr_param%epsilon_y = 1e-9      ! Vertical emittance.
  	seg_len = 0.01                    ! Segment length for calculation.
  	wall_file = "l3.dat" ! "NONE" => Use a wall with a fixed offset from the beam.
  	wall_offset = 0.0448             ! Used when wall_file is set to "NONE"
  /


  • Power density electrons png
  • Linear power density electrons png
  • and electrons tabulated
