The following single hole alumina ceramic tube type insulators are available in six inch lengths. The tubes are constructed of a pure 99% alumina ceramic that has superior gas and vacuum tightness and excellent insulating properties even at elevated temperatures. They are recommended for use in mass spectrometers and other vacuum systems as feed through lines, thermocouple insulators, and in other applications requiring electrical and thermal insulators. Other types are also available - two hole, four hole insulator tubes, and solid rods.
The following ceramic tubes are supplied in 6 inch lengths. Unless otherwise noted they can also be supplied in longer lengths (up to 24 inches long). We can also custom cut shorter lengths to your specifications. Contact us with your specific requirements.
Other sizes available on request
Tolerances on all diameters are ±0.005"
UOM=EA | ||||||||
Part No. | OD (in) | ID (in) | Length (in) | est wt. |
Quantity In Stock |
Price | Quantity to order |
|
---|---|---|---|---|---|---|---|---|
R1195 | Single Hole Round Ceramic Insulator | |||||||
0.020 | 0.008 | --- | 0.25 | 0(#) | $41.00 | |||
R1196 | Single Hole Round Ceramic Insulator | |||||||
0.025 | 0.012 | --- | 0.25 | 0(#) | $34.00 | |||
R17 | Single Hole Round Ceramic Insulator | |||||||
0.031 | 0.020 | --- | 0.25 | 0(#) | $30.00(*A) | |||
R1198 | Single Hole Round Ceramic Insulator | |||||||
0.047 | 0.016 | --- | 0.25 | 0(#) | $12.50 | |||
R44 | Single Hole Round Ceramic Insulator | |||||||
0.050 | 0.020 | --- | 0.25 | 0(#) | $12.50 | |||
R16 | Single Hole Round Ceramic Insulator | |||||||
0.062 | 0.031 | --- | 0 | 0(#) | $12.50 | |||
R1200 | Single Hole Round Ceramic Insulator | |||||||
0.078 | 0.047 | --- | 0.25 | 0(#) | $18.00 | |||
R45 | Single Hole Round Ceramic Insulator | |||||||
0.094 | 0.040 | --- | 0.25 | 0(#) | $12.50 | |||
R1201 | Single Hole Round Ceramic Insulator | |||||||
0.094 | 0.062 | --- | 0.25 | 0(#) | $12.50 | |||
R46 | Single Hole Round Ceramic Insulator | |||||||
0.100 | 0.050 | --- | 0.25 | 0(#) | $12.50 | |||
R15 | Lead Protector for HP Source, Single Hole Round Ceramic Insulator, HP #4330-0624 | |||||||
0.125 | 0.062 | 6.0 | 0.25 | 0(#) | $12.50 | |||
R18 | Single Hole Round Ceramic Insulator | |||||||
0.156 | 0.093 | --- | 0.25 | 0(#) | $12.50 | |||
R14 | Single Hole Round Ceramic Insulator | |||||||
0.188 | 0.062 | --- | 0.25 | 0(#) | $12.50 | |||
R13 | Single Hole Round Ceramic Insulator | |||||||
0.188 | 0.094 | --- | 0.25 | 0(#) | $12.50 | |||
R19 | Single Hole Round Ceramic Insulator | |||||||
0.188 | 0.125 | --- | 0.25 | 0(#) | $12.50 | |||
R50 | Single Hole Round Ceramic Insulator | |||||||
0.218 | 0.156 | --- | 0.25 | 0(#) | $12.50 | |||
R1206 | Single Hole Round Ceramic Insulator | |||||||
0.219 | 0.109 | --- | 0.25 | 0(#) | $12.50 | |||
R12 | Single Hole Round Ceramic Insulator | |||||||
0.250 | 0.062 | --- | 0.25 | 0(#) | $12.50 | |||
R11 | Single Hole Round Ceramic Insulator | |||||||
0.250 | 0.094 | --- | 0.25 | 0(#) | $12.00 | |||
R10 | Single Hole Round Ceramic Insulator | |||||||
0.250 | 0.125 | --- | 0.25 | 0(#) | $12.50 | |||
R1209 | Single Hole Round Ceramic Insulator | |||||||
0.250 | 0.187 | --- | 0.25 | 0(#) | $12.50 | |||
(*_) Marked parts have bulk quantity discount pricing:
Discount code 'A' -- 10 or more: 5% off; 50 or more: 10% off.
| ||||||||
(#) Standard lead-time for out-of-stock items is approximately two weeks. | ||||||||
![]() |
* R11, R12, R14, and R17 are available in 6in lengths only. Prices given per 6in lengths.
SIS Catalog Cross Reference | |
---|---|
Page # | Part Numbers |
A73 - Ceramic Tubes | R10, R11, R1195, R1196, R1198, R12, R1200, R1201, R1206, R1209, R13, R14, R15, R16, R17, R18, R19, R44, R45, R46, R50 |
B13 - Agilent 5989 Engine Accessories by S.I.S.™ | R15 |
