!+ ! Fri Oct 20 13:20:30 2006 => Documented by latdoc. ! Beam energy is 1.885 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.53 9.60 206.7 235.2 124.5 ! e- 0.52 0.60 204.1 235.5 116.1 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 1.01 0.0118 -0.095 -0.078 0.036 0.041 -3.212 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! 0.11 -0.0000 0.007 0.036 0.235 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 2.78 8.654 -0.249 0.203 -0.042 0.027 ! ! IP_L0 disp.: e+ x:9.45e-05 y:1.82e-06 e- x:1.04e-04 y:-1.81e-06 ! ! IP_L0 cbar: -2.3e-04 -1.5e-03 IP_L3 cbar: 6.0e-04 6.3e-04 ! -8.1e-02 -6.2e-04 -1.5e-03 6.4e-04 ! ! Peak Arc Betas: e+ Bx:44.7 By:42.6 e- Bx:45.5 By:43.3 ! H_Sep Bx: 08w:26.49 08e:26.49 45w:9.59 45e:9.59 ! V_Sep By: 48w:9.63 48e:9.63 ! sc wiggler beta y's (wig1_14 -> wig3_18): ! e+ west: 14.64 8.94 22.19 14.05 22.89 26.69 ! e- west: 14.42 8.58 23.84 12.64 20.46 23.80 ! e+ east: 17.47 13.84 16.88 5.30 13.80 21.75 ! e- east: 17.25 13.91 16.12 5.87 15.48 24.43 ! ! 9x5 info: Pr_apert:4.06e-02 Effic:0.47 I_bunch:3.57 B_param_i:2.42 ! Worst x disp e+:-2.02e-02 at: Q34W, e-:1.99e-02 at: Q34W ! 34w: e+ Bx:34.83 e- Bx:38.07 e+ Eta:1.47 Ring sigma_sep:6.67 ! 34e: e+ Bx:44.04 e- Bx:45.31 e- Eta:1.57 ! ! Full turn 4x4 det: 2.91 Momentum_comp: 1.13e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:-1.3e-08 y:-7.4e-07 ! Qs-2Qx Mag e+: 15.13 e-: 17.42 ! *IP* dbeta(dE) x:-22.47 y:-75.99 dbeta(dPretz) x:1.11e+00 y:5.40e-02 ! *max* dbeta(dE) x:-23.47 y:104.90 dbeta(dPretz) x:1.43e+00 y:1.90e-01 ! Chrom x:0.46 y:1.56 Tonality x:0.57 y:-0.20 !- lattice := 10WIG_NO15S_V01 call, file=BMAD_LAYOUT:layout_c_12wig_2005_03_23.bmad call, file=BMAD_LAYOUT:10wig_track.bmad
Last modified: Wed Jul 11 10:23:32 2007 Mike Forster
