!+ ! Fri Oct 20 13:21:24 2006 => Documented by latdoc. ! Beam energy is 4.730 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.53 9.63 206.7 245.3 345.6 ! e- 0.53 0.63 207.3 245.0 236.3 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 0.89 0.0173 0.000 -0.079 -0.100 0.011 -2.412 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! 0.01 -0.0003 0.000 -0.156 -0.032 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 2.52 7.774 -0.311 0.094 0.023 -0.007 ! ! IP_L0 disp.: e+ x:4.13e-05 y:-2.51e-06 e- x:3.09e-06 y:2.51e-06 ! ! IP_L0 cbar: -3.0e-04 1.5e-04 IP_L3 cbar: 3.1e-04 -3.6e-05 ! -4.2e-02 -3.1e-04 -1.6e-04 3.5e-04 ! ! Peak Arc Betas: e+ Bx:42.4 By:42.1 e- Bx:42.2 By:44.0 ! H_Sep Bx: 08w:32.25 08e:32.25 45w:9.31 45e:9.31 ! V_Sep By: 48w:9.40 48e:9.40 ! ! 9x5 info: Pr_apert:4.80e-02 Effic:0.55 I_bunch:2.70 B_param_i:2.81 ! Worst x disp e+:-1.82e-02 at: Q34W, e-:1.79e-02 at: Q34W ! 34w: e+ Bx:37.86 e- Bx:41.98 e+ Eta:1.58 Ring sigma_sep:4.57 ! 34e: e+ Bx:42.39 e- Bx:38.00 e- Eta:1.56 ! ! Full turn 4x4 det: 0.20 Momentum_comp: 1.14e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:-1.3e-09 y:-2.3e-08 ! Qs-2Qx Mag e+: 5.76 e-: 3.60 ! *IP* dbeta(dE) x:10.25 y:-6.93 dbeta(dPretz) x:3.05e-03 y:-1.16e-02 ! *max* dbeta(dE) x:14.37 y:60.91 dbeta(dPretz) x:1.65e-01 y:1.42e-01 ! Chrom x:-0.99 y:-1.25 Tonality x:-0.01 y:0.09 !- lattice = 1s_v2 call, file=BMAD_LAYOUT:cesr_iii_layout.bmad !----------------------------------------------------- !-----------------------------------------------------
