!+ ! Fri Oct 20 13:21:28 2006 => Documented by latdoc. ! Beam energy is 3.500 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.53 9.60 206.7 234.8 429.2 ! e- 0.53 0.60 205.4 233.8 204.5 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 0.99 0.0185 0.003 -0.266 -0.195 0.053 -2.598 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! -0.05 -0.0002 0.004 -0.633 -0.026 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 1.85 5.413 -0.107 0.324 0.169 -0.004 ! ! IP_L0 disp.: e+ x:6.02e-05 y:-1.07e-05 e- x:7.14e-05 y:1.08e-05 ! ! IP_L0 cbar: 1.5e-03 2.5e-02 IP_L3 cbar: 1.0e-03 -5.3e-03 ! -9.5e-02 -5.8e-03 1.1e-02 2.8e-03 ! ! Peak Arc Betas: e+ Bx:55.1 By:49.3 e- Bx:56.6 By:48.7 ! H_Sep Bx: 08w:32.09 08e:32.09 45w:16.17 45e:16.17 ! V_Sep By: 48w:13.65 48e:13.65 ! ! 9x5 info: Pr_apert:5.66e-02 Effic:0.45 I_bunch:1.62 B_param_i:1.80 ! Worst x disp e+:-1.93e-02 at: Q34W, e-:1.91e-02 at: Q34W ! 34w: e+ Bx:30.12 e- Bx:56.28 e+ Eta:2.10 Ring sigma_sep:4.90 ! 34e: e+ Bx:55.12 e- Bx:28.66 e- Eta:2.18 ! ! Full turn 4x4 det: 0.58 Momentum_comp: 1.13e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:-2.6e-09 y:-2.3e-08 ! Qs-2Qx Mag e+: 13.00 e-: 13.68 ! *IP* dbeta(dE) x:-12.87 y:-118.10 dbeta(dPretz) x:1.36e-02 y:6.76e-03 ! *max* dbeta(dE) x:40.89 y:122.00 dbeta(dPretz) x:4.28e-01 y:9.54e-02 ! Chrom x:-0.27 y:1.36 Tonality x:0.41 y:0.54 !- lattice := 3500MEV call, file=BMAD_LAYOUT:cesr_iii_layout.bmad !----------------------------------------------------- !-----------------------------------------------------
