!+ ! Fri Oct 20 13:21:39 2006 => Documented by latdoc. ! Beam energy is 1.995 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.54 9.59 210.6 228.2 136.1 ! e- 0.54 0.58 210.2 226.1 143.4 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 0.98 0.0118 0.013 0.075 0.084 0.013 -3.237 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! 0.22 0.0011 -0.008 0.123 0.137 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 2.29 6.059 0.200 -0.151 -0.021 -0.002 ! ! IP_L0 disp.: e+ x:-2.80e-04 y:2.12e-06 e- x:-7.67e-05 y:-2.10e-06 ! ! IP_L0 cbar: 1.1e-03 -1.7e-03 IP_L3 cbar: -4.5e-04 1.1e-03 ! -7.7e-02 7.4e-04 -1.9e-03 -8.9e-04 ! ! Peak Arc Betas: e+ Bx:47.1 By:47.2 e- Bx:46.5 By:48.7 ! H_Sep Bx: 08w:24.05 08e:24.05 45w:9.05 45e:9.05 ! V_Sep By: 48w:13.69 48e:13.69 ! sc wiggler beta y's (wig1_14 -> wig3_18): ! e+ west: 18.68 10.27 19.20 9.88 17.96 24.43 ! e- west: 15.51 8.16 24.64 9.13 15.63 20.55 ! e+ east: 19.58 13.91 17.30 3.44 8.91 15.54 ! e- east: 21.59 15.80 14.64 3.27 9.28 16.79 ! ! 9x5 info: Pr_apert:4.53e-02 Effic:0.52 I_bunch:3.52 B_param_i:2.46 ! Worst x disp e+:-1.87e-02 at: Q06E, e-:1.97e-02 at: Q34W ! 34w: e+ Bx:46.25 e- Bx:37.06 e+ Eta:2.61 Ring sigma_sep:7.50 ! 34e: e+ Bx:35.33 e- Bx:46.17 e- Eta:2.78 ! ! Full turn 4x4 det: 1.58 Momentum_comp: 1.14e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:-5.8e-10 y:1.0e-06 ! Qs-2Qx Mag e+: 2.01 e-: 5.45 ! *IP* dbeta(dE) x:-8.18 y:-21.76 dbeta(dPretz) x:4.15e-01 y:1.05e-01 ! *max* dbeta(dE) x:-8.28 y:77.60 dbeta(dPretz) x:6.48e-01 y:2.24e-01 ! Chrom x:1.13 y:0.49 Tonality x:-0.21 y:1.00 !- lattice := 3990_MIN_V1 call, file = BMAD_LAYOUT:layout_c_12wig_2005_06_17_19kg.bmad call, file=BMAD_LAYOUT:12wig_track.bmad
Last modified: Fri Nov 17 15:48:06 2006 Mike Forster
