!+ ! Fri Oct 20 13:22:10 2006 => Documented by latdoc. ! Beam energy is 5.175 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.53 9.61 206.7 239.5 153.8 ! e- 0.53 0.62 206.0 240.1 158.7 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 1.24 0.0171 0.008 0.129 -0.067 0.036 -2.822 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! 0.04 0.0001 0.005 0.197 -0.001 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 1.74 6.921 -0.075 -0.117 0.068 -0.003 ! ! IP_L0 disp.: e+ x:6.11e-05 y:-9.78e-07 e- x:-6.72e-05 y:9.79e-07 ! ! IP_L0 cbar: -1.3e-04 4.2e-04 IP_L3 cbar: 1.5e-04 -9.4e-05 ! -4.4e-02 -9.8e-05 5.0e-05 1.9e-04 ! ! Peak Arc Betas: e+ Bx:46.0 By:42.2 e- Bx:45.4 By:42.4 ! H_Sep Bx: 08w:26.01 08e:26.01 45w:13.51 45e:13.51 ! V_Sep By: 48w:10.66 48e:10.66 ! ! 9x5 info: Pr_apert:4.08e-02 Effic:0.40 I_bunch:6.23 B_param_i:5.67 ! Worst x disp e+:-1.81e-02 at: Q08E, e-:1.80e-02 at: Q08E ! 34w: e+ Bx:46.00 e- Bx:36.95 e+ Eta:2.06 Ring sigma_sep:4.97 ! 34e: e+ Bx:35.59 e- Bx:42.44 e- Eta:2.14 ! ! Full turn 4x4 det: 0.48 Momentum_comp: 1.14e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:4.3e-09 y:-1.5e-07 ! Qs-2Qx Mag e+: 7.79 e-: 7.19 ! *IP* dbeta(dE) x:7.87 y:-24.00 dbeta(dPretz) x:1.01e-02 y:4.27e-03 ! *max* dbeta(dE) x:7.27 y:63.44 dbeta(dPretz) x:2.66e-01 y:9.55e-02 ! Chrom x:2.67 y:-1.40 Tonality x:-0.04 y:-0.25 !- lattice := 3s_v2 call, file=BMAD_LAYOUT:cesr_iii_layout.bmad !----------------------------------------------------- !-----------------------------------------------------
Last modified: Fri Nov 17 15:48:06 2006 Mike Forster
