!+ ! Fri Oct 20 13:22:37 2006 => Documented by latdoc. ! Beam energy is 2.007 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.54 9.59 210.6 228.2 137.8 ! e- 0.54 0.58 209.5 226.0 146.1 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 1.00 0.0119 0.016 0.074 0.083 0.013 -3.225 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! 0.26 0.0012 -0.004 0.124 0.137 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 2.27 6.040 0.199 -0.148 -0.021 -0.001 ! ! IP_L0 disp.: e+ x:-2.80e-04 y:2.10e-06 e- x:-7.48e-05 y:-2.10e-06 ! ! IP_L0 cbar: 1.1e-03 -1.8e-03 IP_L3 cbar: -4.4e-04 1.1e-03 ! -7.7e-02 7.4e-04 -1.9e-03 -8.9e-04 ! ! Peak Arc Betas: e+ Bx:47.1 By:47.2 e- Bx:47.2 By:48.7 ! H_Sep Bx: 08w:23.91 08e:23.91 45w:9.09 45e:9.09 ! V_Sep By: 48w:13.74 48e:13.74 ! sc wiggler beta y's (wig1_14 -> wig3_18): ! e+ west: 18.73 10.30 19.15 9.90 18.00 24.50 ! e- west: 15.47 8.13 24.72 9.12 15.59 20.49 ! e+ east: 19.65 13.96 17.24 3.44 8.93 15.59 ! e- east: 21.50 15.73 14.70 3.27 9.24 16.72 ! ! 9x5 info: Pr_apert:4.55e-02 Effic:0.52 I_bunch:3.51 B_param_i:2.45 ! Worst x disp e+:-1.87e-02 at: Q06E, e-:1.98e-02 at: Q34W ! 34w: e+ Bx:46.09 e- Bx:37.34 e+ Eta:2.61 Ring sigma_sep:7.47 ! 34e: e+ Bx:35.42 e- Bx:46.94 e- Eta:2.78 ! ! Full turn 4x4 det: 1.57 Momentum_comp: 1.14e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:-9.0e-10 y:1.0e-06 ! Qs-2Qx Mag e+: 1.52 e-: 5.72 ! *IP* dbeta(dE) x:-7.42 y:-22.04 dbeta(dPretz) x:4.66e-01 y:9.84e-02 ! *max* dbeta(dE) x:-7.51 y:75.95 dbeta(dPretz) x:6.92e-01 y:2.18e-01 ! Chrom x:1.19 y:0.47 Tonality x:0.11 y:1.00 !- lattice := 4015_MIN_V1 call, file = BMAD_LAYOUT:layout_c_12wig_2005_06_17_19kg.bmad call, file=BMAD_LAYOUT:12wig_track.bmad
Last modified: Fri Nov 17 15:48:06 2006 Mike Forster
