!+ ! Fri Oct 20 13:20:01 2006 => Documented by latdoc. ! Beam energy is 2.060 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.54 9.58 210.6 227.8 145.4 ! e- 0.54 0.58 208.7 225.9 156.4 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 0.99 0.0120 0.017 0.071 0.070 0.014 -3.101 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! 0.29 0.0012 -0.001 0.117 0.111 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 2.33 6.013 0.198 -0.155 -0.012 -0.002 ! ! IP_L0 disp.: e+ x:-6.39e-04 y:-1.38e-05 e- x:-7.98e-05 y:-2.27e-06 ! ! IP_L0 cbar: 1.1e-03 -1.2e-03 IP_L3 cbar: -6.2e-04 -1.2e-03 ! -7.6e-02 5.4e-04 -9.6e-04 -9.9e-04 ! ! Peak Arc Betas: e+ Bx:46.8 By:46.8 e- Bx:48.7 By:49.1 ! H_Sep Bx: 08w:24.50 08e:24.50 45w:8.99 45e:8.99 ! V_Sep By: 48w:13.82 48e:13.82 ! sc wiggler beta y's (wig1_14 -> wig3_18): ! e+ west: 18.74 10.33 19.01 9.87 17.99 24.51 ! e- west: 15.57 8.16 24.79 9.19 15.69 20.60 ! e+ east: 19.81 14.05 17.20 3.47 9.01 15.71 ! e- east: 21.46 15.73 14.67 3.24 9.21 16.69 ! ! 9x5 info: Pr_apert:4.92e-02 Effic:0.51 I_bunch:3.41 B_param_i:2.39 ! Worst x disp e+:-2.35e-02 at: Q34W, e-:1.99e-02 at: Q34W ! 34w: e+ Bx:46.42 e- Bx:37.78 e+ Eta:2.60 Ring sigma_sep:7.36 ! 34e: e+ Bx:35.30 e- Bx:48.45 e- Eta:2.78 ! ! Full turn 4x4 det: 1.83 Momentum_comp: 1.14e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:-2.3e-10 y:1.0e-06 ! Qs-2Qx Mag e+: 0.03 e-: 4.84 ! *IP* dbeta(dE) x:-0.05 y:4.55 dbeta(dPretz) x:1.55e+02 y:4.39e+00 ! *max* dbeta(dE) x:-0.04 y:69.38 dbeta(dPretz) x:2.94e+02 y:1.99e+01 ! Chrom x:0.37 y:-0.59 Tonality x:0.36 y:1.01 !- lattice := 4120_MIN_V1 call, file = BMAD_LAYOUT:layout_c_12wig_2005_06_17_19kg.bmad call, file=BMAD_LAYOUT:12wig_track.bmad
