!+ ! Fri Oct 20 13:21:56 2006 => Documented by latdoc. ! Beam energy is 2.100 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.52 9.59 202.8 228.2 121.6 ! e- 0.52 0.58 201.3 227.8 126.7 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 0.88 0.0119 -0.000 0.039 0.025 0.002 -2.969 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! 0.02 0.0006 -0.009 -0.123 -0.012 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 1.97 6.480 -0.262 -0.083 -0.035 0.032 ! ! IP_L0 disp.: e+ x:-1.79e-04 y:-9.79e-07 e- x:1.67e-04 y:9.44e-07 ! ! IP_L0 cbar: -8.5e-04 2.4e-03 IP_L3 cbar: 3.2e-03 -2.0e-03 ! -3.1e-03 -1.9e-03 1.6e-03 1.6e-03 ! ! Peak Arc Betas: e+ Bx:43.2 By:43.9 e- Bx:43.6 By:45.7 ! H_Sep Bx: 08w:30.95 08e:30.95 45w:8.52 45e:8.52 ! V_Sep By: 48w:12.79 48e:12.79 ! sc wiggler beta y's (wig1_14 -> wig3_18): ! e+ west: 12.42 6.18 32.49 8.58 13.62 17.44 ! e- west: 11.28 5.21 40.40 9.39 13.84 16.76 ! e+ east: 17.79 10.66 30.52 5.39 10.13 14.83 ! e- east: 17.86 11.21 25.92 4.66 9.45 14.60 ! ! 9x5 info: Pr_apert:4.02e-02 Effic:0.50 I_bunch:3.23 B_param_i:2.20 ! Worst x disp e+:1.75e-02 at: Q06W, e-:-1.78e-02 at: Q06W ! 34w: e+ Bx:43.20 e- Bx:40.90 e+ Eta:2.68 Ring sigma_sep:5.54 ! 34e: e+ Bx:33.88 e- Bx:35.33 e- Eta:2.52 ! ! Full turn 4x4 det: 1.03 Momentum_comp: 1.12e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:-5.1e-10 y:7.5e-07 ! Qs-2Qx Mag e+: 2.20 e-: 1.44 ! *IP* dbeta(dE) x:-14.08 y:-35.16 dbeta(dPretz) x:-1.13e-01 y:2.56e-02 ! *max* dbeta(dE) x:57.92 y:107.50 dbeta(dPretz) x:2.42e-01 y:1.27e-01 ! Chrom x:1.01 y:0.62 Tonality x:0.45 y:0.19 !- lattice := 4200_100305 call, file = BMAD_LAYOUT:layout_c_12wig_2005_06_17_19kg.bmad call, file=BMAD_LAYOUT:12wig_track.bmad
Last modified: Fri Nov 17 15:48:06 2006 Mike Forster
