!+ ! Fri Oct 20 13:20:35 2006 => Documented by latdoc. ! Beam energy is 2.130 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.54 9.59 210.6 228.2 155.6 ! e- 0.54 0.58 210.3 226.1 166.0 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 0.91 0.0122 0.013 0.076 0.087 0.013 -3.225 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! 0.19 0.0012 -0.009 0.125 0.141 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 2.49 5.986 0.200 -0.170 -0.025 -0.002 ! ! IP_L0 disp.: e+ x:-2.84e-04 y:2.08e-06 e- x:-7.88e-05 y:-2.12e-06 ! ! IP_L0 cbar: 1.1e-03 -1.4e-03 IP_L3 cbar: -5.1e-04 3.6e-04 ! -6.9e-02 6.9e-04 -1.6e-03 -9.3e-04 ! ! Peak Arc Betas: e+ Bx:47.3 By:47.4 e- Bx:48.1 By:48.9 ! H_Sep Bx: 08w:25.96 08e:25.96 45w:8.80 45e:8.80 ! V_Sep By: 48w:13.85 48e:13.85 ! sc wiggler beta y's (wig1_14 -> wig3_18): ! e+ west: 18.90 10.38 19.07 9.99 18.18 24.73 ! e- west: 15.70 8.28 24.29 9.20 15.80 20.81 ! e+ east: 19.76 14.06 17.08 3.43 8.97 15.69 ! e- east: 21.90 16.02 14.46 3.30 9.40 17.03 ! ! 9x5 info: Pr_apert:4.73e-02 Effic:0.50 I_bunch:3.24 B_param_i:2.29 ! Worst x disp e+:1.88e-02 at: Q34E, e-:1.98e-02 at: Q34W ! 34w: e+ Bx:47.33 e- Bx:37.52 e+ Eta:2.61 Ring sigma_sep:7.10 ! 34e: e+ Bx:35.19 e- Bx:47.77 e- Eta:2.78 ! ! Full turn 4x4 det: 1.93 Momentum_comp: 1.14e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:1.8e-09 y:9.5e-07 ! Qs-2Qx Mag e+: 3.43 e-: 7.20 ! *IP* dbeta(dE) x:-6.74 y:-23.31 dbeta(dPretz) x:4.69e-01 y:8.15e-02 ! *max* dbeta(dE) x:-6.79 y:74.72 dbeta(dPretz) x:7.10e-01 y:1.99e-01 ! Chrom x:1.10 y:0.47 Tonality x:-0.20 y:1.00 !- lattice := 4260_MIN_V1 call, file = BMAD_LAYOUT:layout_c_12wig_2005_06_17_19kg.bmad call, file=BMAD_LAYOUT:12wig_track.bmad
Last modified: Fri Nov 17 15:48:06 2006 Mike Forster
