!+ ! Fri Oct 20 13:21:03 2006 => Documented by latdoc. ! Beam energy is 1.835 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.53 9.59 206.7 230.5 180.3 ! e- 0.53 0.58 206.7 227.8 164.5 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 0.54 0.0132 -0.015 -0.038 -0.193 0.004 -3.783 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! 0.01 0.0008 -0.011 -0.102 -0.025 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 1.59 8.753 -0.165 0.140 0.104 0.015 ! ! IP_L0 disp.: e+ x:-3.99e-04 y:-5.32e-07 e- x:4.10e-04 y:5.21e-07 ! ! IP_L0 cbar: -3.3e-04 7.7e-05 IP_L3 cbar: -9.7e-05 2.1e-04 ! 1.3e-04 -1.2e-04 -2.5e-04 2.7e-04 ! ! Peak Arc Betas: e+ Bx:41.5 By:43.5 e- Bx:44.1 By:43.4 ! H_Sep Bx: 08w:29.69 08e:29.69 45w:12.49 45e:12.49 ! V_Sep By: 48w:10.07 48e:10.07 ! sc wiggler beta y's (wig1_14 -> wig3_18): ! e+ west: 0.01 0.01 0.01 0.01 0.01 0.01 ! e- west: 0.01 0.01 0.01 0.01 0.01 0.01 ! e+ east: 17.68 14.42 16.17 2.91 7.07 11.49 ! e- east: 18.46 15.33 14.62 2.69 6.93 11.68 ! ! 9x5 info: Pr_apert:4.50e-02 Effic:0.24 I_bunch:0.76 B_param_i:1.44 ! Worst x disp e+:-1.93e-02 at: Q00W\CLEO_, e-:1.94e-02 at: Q00W\CLEO_ ! 34w: e+ Bx:37.11 e- Bx:37.18 e+ Eta:2.77 Ring sigma_sep:3.39 ! 34e: e+ Bx:39.08 e- Bx:38.12 e- Eta:2.45 ! ! Full turn 4x4 det: 1.59 Momentum_comp: 1.13e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:6.1e-09 y:-2.9e-07 ! Qs-2Qx Mag e+: 3.31 e-: 7.40 ! *IP* dbeta(dE) x:-5.75 y:-27.50 dbeta(dPretz) x:2.26e-01 y:5.72e-03 ! *max* dbeta(dE) x:117.50 y:152.50 dbeta(dPretz) x:3.48e-01 y:9.18e-02 ! Chrom x:0.50 y:-0.42 Tonality x:0.01 y:1.40 !- ! starting point ==> lattice := 6wig_lum_20030915_v4 lattice := 6wig_1835mev_20031222_v1 call, file=BMAD_LAYOUT:layout_c_6wig_2003_07_08.bmad call, file=BMAD_LAYOUT:6wig_track.bmad call, file =BMAD_LAYOUT:multi_wig.bmad
Last modified: Fri Nov 17 15:48:06 2006 Mike Forster
