!+ ! Fri Oct 20 13:20:41 2006 => Documented by latdoc. ! Beam energy is 5.289 GeV ! Qx Qy Fx Fy Emitt(nm rad) ! e+ 10.55 9.60 214.5 233.2 107.0 ! e- 0.55 0.60 215.4 233.7 111.7 ! ! Bx* By* Eta* Alphax* Alphay* Eta'* Cr_ang(mrad) ! 1.25 0.0304 0.408 0.107 0.124 0.071 -2.357 ! ! Bx* By* Eta* Alphax* Alphay* -> Positron-Electron ! -0.08 0.0001 -0.036 -0.236 0.022 ! ! Bx By Eta Alphax Alphay Eta' -> all at IP_L3 ! 7.14 2.991 0.190 0.270 -0.114 0.025 ! ! IP_L0 disp.: e+ x:9.84e-05 y:7.11e-05 e- x:2.46e-04 y:-7.09e-05 ! ! IP_L0 cbar: 1.9e-02 -1.5e-01 IP_L3 cbar: 7.5e-04 -1.1e-04 ! -5.8e-02 -1.7e-02 1.1e-04 2.9e-04 ! ! Peak Arc Betas: e+ Bx:48.6 By:55.1 e- Bx:47.0 By:52.9 ! H_Sep Bx: 08w:17.38 08e:17.38 45w:19.33 45e:19.33 ! V_Sep By: 48w:14.04 48e:14.04 ! ! 9x5 info: Pr_apert:3.91e-02 Effic:0.46 I_bunch:9.42 B_param_i:8.49 ! Worst x disp e+:1.82e-02 at: Q10W, e-:-1.82e-02 at: Q34E ! 34w: e+ Bx:38.18 e- Bx:46.95 e+ Eta:2.73 Ring sigma_sep:6.86 ! 34e: e+ Bx:47.95 e- Bx:39.25 e- Eta:2.53 ! ! Full turn 4x4 det: 0.33 Momentum_comp: 1.11e-02 ! sync_beta_path x:0.0e+00 y:0.0e+00 _volt x:-1.1e-09 y:1.1e-07 ! Qs-2Qx Mag e+: 7.98 e-: 13.70 ! *IP* dbeta(dE) x:30.85 y:-12.82 dbeta(dPretz) x:-2.82e-03 y:1.28e-02 ! *max* dbeta(dE) x:30.81 y:40.30 dbeta(dPretz) x:2.79e-01 y:1.14e-01 ! Chrom x:1.89 y:1.78 Tonality x:0.02 y:-0.28 !- lattice=CHESS_20050617 call, file=BMAD_LAYOUT:layout_antisol_2006_02_23_19kg.bmad call, file=BMAD_LAYOUT:12wig_off.bmad !----------------------------------------------------- !-----------------------------------------------------
Last modified: Fri Nov 17 15:48:06 2006 Mike Forster
